Rigol DS1104Z Plus Programming Guide

Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-163
:TRIGger:EDGe:LEVel
Syntax
:TRIGger:EDGe:LEVel <level>
:TRIGger:EDGe:LEVel?
Description
Set or query the trigger level in edge trigger. The unit is the same as the current
amplitude unit of the signal source selected.
Parameter
Name
Type
Range
Default
<level>
Real
(-5 x VerticalScale - OFFSet) to
(5 x VerticalScale - OFFSet)
0
Explanation
 For VerticalScale, refer to the :CHANnel<n>:SCALe command. For OFFSet, refer to
the :CHANnel<n>:OFFSet command.
 This command is only available when the signal source is an analog channel.
Return
Format
The query returns the trigger level in scientific notation.
Example
:TRIGger:EDGe:LEVel 0.16 /*Set the trigger level to 160mV*/
:TRIGger:EDGe:LEVel? /*The query returns 1.600000e-01*/

Rigol DS1104Z Plus Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Timebase Range	5 ns/div to 50 s/div
Connectivity	USB Host, USB Device, LAN, AUX
Vertical Resolution	8 bits
Power Supply	100-240 V AC, 45-440 Hz
Display	7 inch TFT LCD
Trigger Types	Edge, Pulse, Video, Slope
Input Impedance	1 MΩ ± 2%
