Rigol DS1104Z Plus Programming Guide

RIGOL Chapter 2 Command System
2-200 MSO1000Z/DS1000Z Programming Guide
:TRIGger:NEDGe:IDLE
Syntax
:TRIGger:NEDGe:IDLE <NR3>
:TRIGger:NEDGe:IDLE?
Description
Set or query the idle time in Nth edge trigger. The default unit is s.
Parameter
Name
Type
Range
Default
<NR3>
Real
16ns to 10s
1μs
Return Format
The query returns the idle time in scientific notation.
Example
:TRIGger:NEDGe:IDLE 0.002 /*Set the idle time to 2ms*/
:TRIGger:NEDGe:IDLE? /*The query returns 2.000000e-03*/
:TRIGger:NEDGe:EDGE
Syntax
:TRIGger:NEDGe:EDGE <NR1>
:TRIGger:NEDGe:EDGE?
Description
Set or query the number of edges in Nth edge trigger.
Parameter
Name
Type
Range
Default
<NR1>
Integer
1 to 65535
2
Return Format
The query returns an integer between 1 and 65535.
Example
:TRIGger:NEDGe:EDGE 20 /*Set the number of edges to 20*/
:TRIGger:NEDGe:EDGE? /*The query returns 20*/
:TRIGger:NEDGe:LEVel
Syntax
:TRIGger:NEDGe:LEVel <level>
:TRIGger:NEDGe:LEVel?
Description
Set or query the trigger level in Nth edge trigger. The unit is the same as the current
amplitude unit.
Parameter
Name
Type
Range
Default
<level>
Real
(-5 x VerticalScale - OFFSet) to
(5 x VerticalScale - OFFSet)
0
Explanation
 For VerticalScale, refer to :CHANnel<n>:SCALe. For OFFSet, refer
to :CHANnel<n>:OFFSet.
 This command is only available when the signal source is an analog channel.
Return Format
The query returns the trigger level in scientific notation.
Example
:TRIGger:NEDGe:LEVel 0.16 /*Set the trigger level to 160mV*/
:TRIGger:NEDGe:LEVel? /*The query returns 1.600000e-01*/

Rigol DS1104Z Plus Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Timebase Range	5 ns/div to 50 s/div
Connectivity	USB Host, USB Device, LAN, AUX
Vertical Resolution	8 bits
Power Supply	100-240 V AC, 45-440 Hz
Display	7 inch TFT LCD
Trigger Types	Edge, Pulse, Video, Slope
Input Impedance	1 MΩ ± 2%
