RIGOL Chapter 2 Command System
2-214 MSO1000Z/DS1000Z Programming Guide
:TRIGger:SPI:SLEVel
Syntax
:TRIGger:SPI:SLEVel <level>
:TRIGger:SPI:SLEVel?
Description
Set or query the trigger level of the CS channel in SPI trigger. The unit is the same as the
current amplitude unit.
Parameter
Name
Type
Range
Default
<level>
Real
(-5 x VerticalScale - OFFSet) to
(5 x VerticalScale - OFFSet)
0
Explanation
 For VerticalScale, refer to :CHANnel<n>:SCALe. For OFFSet, refer
to :CHANnel<n>:OFFSet.
 This command is only available when the signal source of the CS line is an analog
channel.
Return
Format
The query returns the trigger level of the CS channel in scientific notation.
Example
:TRIGger:SPI:SLEVel 0.16 /*Set the trigger level of the CS channel to 160mV*/
:TRIGger:SPI:SLEVel? /*The query returns 1.600000e-01*/
:TRIGger:SPI:MODE
Syntax
:TRIGger:SPI:MODE <mode>
:TRIGger:SPI:MODE?
Description
Set or query the CS mode when the trigger condition is CS in SPI trigger.
Parameter
Name
Type
Range
Default
<mode>
Discrete
{HIGH|LOW}
LOW
Return
Format
The query returns HIGH or LOW.
Example
:TRIGger:SPI:MODE LOW /*Set the CS mode to low*/
:TRIGger:SPI:MODE? /*The query returns LOW*/
Related
Command
:TRIGger:SPI:WHEN

Rigol DS1104Z Plus Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Timebase Range	5 ns/div to 50 s/div
Connectivity	USB Host, USB Device, LAN, AUX
Vertical Resolution	8 bits
Power Supply	100-240 V AC, 45-440 Hz
Display	7 inch TFT LCD
Trigger Types	Edge, Pulse, Video, Slope
Input Impedance	1 MΩ ± 2%
