Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-49
:DECoder<n>:IIC:ADDRess
Syntax
:DECoder<n>:IIC:ADDRess <addr>
:DECoder<n>:IIC:ADDRess?
Description
Set or query the address mode of I2C decoding.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2}
--
<addr>
Discrete
{NORMal|RW}
NORMal
Explanation
 NORMal: the address bits (:TRIGger:IIC:AWIDth) does not include the R/W bit.
 RW: the address bits (:TRIGger:IIC:AWIDth) includes the R/W bit.
Return
Format
The query returns NORM or RW.
Example
:DECoder1:IIC:ADDRess RW /*Set the address of I2C decoding to include the R/W
bit*/
:DECoder1:IIC:ADDRess? /*The query returns RW*/
