Rigol DS1104Z Plus Programming Guide

Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-61
:DECoder<n>:PARallel:PLOT
Syntax
:DECoder<n>:PARallel:PLOT <bool>
:DECoder<n>:PARallel:PLOT?
Description
Turn on or off the curve function of parallel decoding, or query the status of the curve
function of parallel decoding.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2}
--
<bool>
Bool
{{1|ON}|{0|OFF}}
0|OFF
Explanation
When this function is turned on, the variation trend of the bus data is displayed in vector
diagram form.
Return
Format
The query returns 1 or 0.
Example
:DECoder1:PARallel:PLOT ON /*Turn on the curve function*/
:DECoder1:PARallel:PLOT? /*The query returns 1*/

Rigol DS1104Z Plus Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Timebase Range	5 ns/div to 50 s/div
Connectivity	USB Host, USB Device, LAN, AUX
Vertical Resolution	8 bits
Power Supply	100-240 V AC, 45-440 Hz
Display	7 inch TFT LCD
Trigger Types	Edge, Pulse, Video, Slope
Input Impedance	1 MΩ ± 2%
