RIGOL Chapter 1 Quick Start
1-22 DS2000E User’s Guide
Note: The following arrow keys might appear in the grid at the lower-left
corner of the operation menu:
Indicates that you can open the next page of the menu.
Indicates that you can open the previous page of the menu.
13. Notification Area
Display the system time, sound icon, and USB storage device icon and PictBridge
printer icon.
 System Time
Displayed in "hh:mm (hour:minute)" format. When printing or storing
the waveform, the output file will contain this time message. Press
Utility  System  System Time  System Time to set in the
following format: yyyy-mm-dd hh:mm:ss (year-month-date
hour:minute:second)
 Sound Icon
When the sound is enabled, will be displayed. Press Utility  Sound to
enable or disable the sound.
 USB Storage Device Icon
When a USB storage device is detected,
will be displayed.
 PictBridge Printer Icon
When a PictBridge printer is correctly connected to the oscilloscope,
will
be displayed in this area.
14. Message Box
Display the prompt messages.
15. CH2 Vertical Scale
Display the on/off status of CH2 and the voltage value per grid of CH2 waveform
vertically. In addition, the following labels will be displayed according to the
current channel setting: channel coupling (e.g.
), input impedance (e.g. )
and bandwidth limit (e.g.
). You can use VIRTICAL SCALE to modify this
parameter.
16. CH1 Vertical Scale
Display the on/off status of CH1 and the voltage value per grid of CH1 waveform
vertically. In addition, the following labels will be displayed according to the
current channel setting: channel coupling (e.g.
), input impedance (e.g. )
