Rigol DS2000E Series User Manual

Chapter 1 Quick Start RIGOL
DS2000E User’s Guide 1-21
10. Trigger Source
Display the trigger source currently selected (CH1, CH2, EXT, or AC Line).
Different labels are displayed when different trigger sources are selected and
the color of the trigger parameter area will change accordingly.
For example,
denotes that CH1 is selected as the trigger source.
11. Trigger Level
 When the trigger source is set to CH1 or CH2, the trigger level label
is
displayed at the right of the screen and the trigger level value is displayed at
the upper-right corner of the screen. When using TRIGGER
LEVEL to
modify the trigger level, the trigger level value will change with the up and
down of
.
 When the trigger source is EXT, the trigger level value is displayed at the
upper-right corner of the screen. No trigger level label is displayed.
 If the trigger source is AC line, no trigger level value and trigger level label
are displayed.
 In Runt trigger, slope trigger and windows trigger, two trigger level labels
(
and ) are displayed.
12. Operation Menu
Press any softkey to activate the corresponding menu. The following icons
might be displayed in the menu:
Indicates that you can use the multi-function knob
to select the
parameters. The backlight of
turns on when the parameter
selection is valid.
Indicates that you can use the multi-function knob
to modify the
parameters. The backlight of
turns on when the parameter input
is valid.
Indicates that you can rotate the "
Navigation Knob
" to quickly
adjust/locate parameters.
Indicates that you can rotate the multi-function knob
to adjust
the parameter and then press down
to select the parameter. The
backlight of
is constant on when the menu with such an icon is
selected.
Indicates that the current menu has several options.
Indicates that the current menu has a submenu.
Press this key to return to the previous menu.
