Front Panel Key Reference RIGOL
User’s Guide for DSA1000 Series
2-53
Table 2-31 The Start Line under T-Power measurement
Parameter Explanation
Default 0 us
Range 0 ms to Stop line
Unit
ks, s, ms, us, ns, ps
Knob Step Sweep time/600
Direction Key Step in 1, 1.5, 2, 3, 5, 7.5 sequence
5. Stop Line
Sets the right margin when measuring the T-Power using the time units. The data
calculated under this measurement is from the start to stop line.
You can use the numeric keys, knob or direction keys to modify this parameter.
For more details, please refer to “Parameter Input”.
Table 2-32 The Stop Line under T-Power measurement
Parameter Explanation
Default 100 ms
Range Start line to Sweep time
Unit
ks, s, ms, us, ns, ps
Knob Step
Sweep time/600
Direction Key Step
in 1, 1.5, 2, 3, 5, 7.5 sequence
