Rigol DSA1030A series User Manual

Front Panel Key Reference RIGOL
User’s Guide for DSA1000 Series
2-91
3. Pk Readout
Sets the peak display condition to Normal, >DL or <DL.
 Normal
Displaying the first ten qualified peaks in the table.
 >DL
Displaying the first ten peaks that not only meet the parameter conditions but
also have an amplitude greater than the specified Display Line (from Display
menu) in the table.
 <DL
Displaying the first ten peaks that not only meet the parameter conditions but
also have an amplitude smaller than the specified Display Line (from Display
menu) in the table.
2.5.5 L-Peak
The shortcut key of the Left peak measurement, which has the same function as the
L-Peak menu under the Peak key: Searches the nearest peak located to the left side
of the current peak and meets the searching condition, and identifies it with a marker.
2.5.6 R-Peak
The shortcut key of the Right peak measurement, which has the same function as the
R-Peak menu under the Peak key: Searches the nearest peak located to the right
side of the current peak and meets the searching condition, and identifies it with a
marker.
