RIGOL Measurement Examples
3-34 User’s Guide for DSA1000 Series
3.15 Amplitude Correction
Edit an amplitude-frequency curve to correct the current measured curve.
Procedures:
1. Enter amplitude correction
－Press AMPT
－Page down
－Press Corrections and enter the lower menu.
2. Select a curve
－Press Select
－Press Antenna
3. Open amplitude correction
－Press Correction to enable or disable the amplitude correction.
－Press Corr Table to turn on or off the correction table.
4. Edit the correction points
－Press Edit and enter the lower menu.
－Press Frequency and enter 100 MHz.
－Press Amplitude and enter 10 dB.
A correction point with 100 MHz and 10 dB is added.
－Press Point and enter 2.
－Press Frequency and enter 200 MHz.
－Press Amplitude and enter 20 dB.
Another correction point with 200 MHz and 20 dB is added.
