Quick Start RIGOL
User’s Guide for DSA1000 Series
1.3.4 Connect the Power
The spectrum analyzer can use AC power or rechargeable battery (China only) for
power supply.
1.3.4.1 Connect the AC Power
Please use the power cord provided for AC powering, see figure below. For the AC
voltage and frequency requirements, refer to “Rear Panel”.
Figure 1-16 Power cord connection
CAUTION
Please ensure the instrument has been grounded correctly to avoid
electrical shock.
