Rigol DSA1030A series User Manual

Measurement Examples RIGOL
User’s Guide for DSA1000 Series
3-1
3 Measurement Examples
This chapter introduces the main functions and operations of the analyzer.
Subjects in this chapter:
 Measuring a Sine Signal
 Using the Frequency Counter
 Measuring an AM Signal
 Measuring the Phase Noise
 Measuring the N dB Bandwidth
 Measuring the Time-Domain Power
 Measuring the Adjacent Channel Power
 Measuring the Channel Power
 Measuring the Occupied Bandwidth
 Measuring the Emission Bandwidth
 Measuring the Carrier-to-Noise Ratio
 Measuring the Harmonic Distortion
 Measuring the TOI Distortion
 Pass/Fail Measurement
 Amplitude Correction
 Tracking Generator (For DSA1030-TG)

Rigol DSA1030A series Specifications

General

Brand	Rigol
Model	DSA1030A series
Category	Measuring Instruments
Language	English
