Rigol DSA1030A series - Power-On Check; Self Calibration; Use the Lock; Figure 1-18 Use the Lock

Quick Start RIGOL
User’s Guide for DSA1000 Series
1-17
1.3.5 Power-On Check
Turn on the power switch at the rear panel, then press down the power button
on the front panel. You can monitor the initialization process according to the progress
indicator during power-on. Upon completion of the initialization process, a sweep
curve would be displayed.
1.3.6 Self Calibration
Press System  Calibrate  Cal Now, to use internal calibration resources to
calibrate the system.
1.3.7 Use the Lock
If necessary, use a security lock to lock the analyzer in a desired location. See figure
below, place the key into the lock hole in the direction of the arrow, turn it clockwise
and then remove the key.
Figure 1-18 Use the lock
Lock
Key
Lock hole
