Rigol DSA1030A series User Manual

Front Panel Key Reference RIGOL
User’s Guide for DSA1000 Series
2-1
2 Front Panel Key Reference
This chapter describes in detail the function keys on the front panel and associated
pull down menus. Note that a third class title such as 2.1.1 FREQ always denotes a
panel key of the analyzer, while a quaternary title such as 2.1.1.1 Center Freq
always denotes a menu softkey of a panel key.
Subjects in this chapter:
 Basic Settings
 Sweep Settings
 Function Settings
 Advanced Measurements (DSA1030/DSA1030-TG Option)
 Marker Measurements
 System Functions
 Screen Control
