Rigol DSA1030A series User Manual

Specification RIGOL
User’s Guide for DSA1000 Series
6-7
6.1.4 Trigger
Trigger
Trigger Source Free run, Video, External
External Trigger Level 5 V TTL level, nominal
6.1.5 Tracking Generator (For DSA1030-TG)
TG Output
Frequency Range
10 MHz to 3 GHz, 9 kHz
settable
Output Level
-20 dBm to 0 dBm, in 1 dB
steps
Output Flatness
10 MHz to 3 GHz,
referenced to 50 MHz
±3 dB
6.1.6 Input/Output
RF Input
Impedance 50 Ω, nominal
Connector N-type, female
TG Out
Impedance 50 Ω, nominal
Connector N-type, female
Probe Power
Voltage/Current +15 V, <10% at 150 mA
-12.6 V, <10% at 150 mA
10 MHz REF In / 10 MHz REF Out / External Trigger In
Connector BNC female
10 MHz REF Amplitude 0 dBm to 10 dBm
Trigger Voltage 5 V TTL level, nominal
