Rigol DSA1030A series User Manual

RIGOL Specification
6-6 User’s Guide for DSA1000 Series
RF Input VSWR (DSA1030)
10 dB RF Attenuation
VSWR
100 kHz to 10 MHz <1.8, nominal
10 MHz to 2.5 GHz <1.5, nominal
2.5 GHz to 3 GHz <1.8, nominal
Intermodulation
Second Harmonic
Intercept (SHI)
+35 dBm
Third-order
Intermodulation (TOI)
fc >30 MHz +7 dBm
Spurious Responses
Image Frequency <-60 dBc
Intermediate Frequency <-60 dBc
Spurious Response <-85 dBm, typical
System-related Sideband
Referenced to local
oscillators, referenced to
A/D conversion,
referenced to
subharmonic of first LO,
referenced to harmonic
of first LO
<-60 dBc
Input Related Spurious Mixer level: -30 dBm <-60 dBc, typical
6.1.3 Sweep
Sweep (DSA1030)
Sweep Time Range
100 Hz ≤ Span ≤ 3 GHz 10 ms to 3000 s
Span=0 Hz 20 μs to 3000 s
Sweep Time Uncertainty
100 Hz ≤ Span ≤ 3 GHz 5%, nominal
Span=0 Hz 0.5%, nominal
Sweep Mode Continuous, Single

Rigol DSA1030A series Specifications

General

Brand	Rigol
Model	DSA1030A series
Category	Measuring Instruments
Language	English
