RIGOL Front Panel Key Reference
2-56 User’s Guide for DSA1000 Series
Table 2-35 The adjacent channel bandwidth of ACP measurement
Parameter Explanation
Default 2 MHz
Range 33 Hz to 1 GHz
Unit
GHz, MHz, kHz, Hz
Knob Step Adj CH BW/100, Min = 1 Hz
Direction Key Step 1, 1.5, 2, 3, 5, 7.5 sequence
5. CH Spacing
Sets the spacing between the main and adjacent channels.
 Changing this parameter may adjust the channel distance from the main to
the upper and lower.
 You can use the numeric keys, knob or direction keys to modify this
parameter. For more details, please refer to “Parameter Input”.
Table 2-36 Spacing of the ACP measurement
Parameter Explanation
Default 2 MHz
Range 33 Hz to 1 GHz
Unit GHz, MHz, kHz, Hz
Knob Step CH Spacing/100, Min = 1 Hz
Direction Key Step in 1, 1.5, 2, 3, 5, 7.5 sequence
