Front Panel Key Reference RIGOL
User’s Guide for DSA1000 Series
3. Save Preset
Saves the current instrument settings as the user-defined setting into the internal
non-volatile memory, and these settings will be recalled when the Preset Type is
set to User.
2.6.1.3 Calibrate
1. Cal Now
The analyzer will use the internal calibration source to perform a self-test as soon
as the menu key is pressed.
2. Self-Cal
This function drives the analyzer to perform a regular self-calibration according to
the environmental temperature so as to compensate for the system error.
2.6.1.4 I/O Settings
This analyzer supports communications through the LAN, USB and GPIB interfaces.
Both LAN and USB are standard interfaces, and GPIB should be configured by using a
USB-GPIB module (option) provided by RIGOL. To get the USB-GPIB module, please
contact RIGOL.
1. Remote I/O
Select LAN, USB or GPIB, or disable all the three interfaces.
2. LAN
Sets or resets the LAN parameters.
