RIGOL Quick Start
1-22 User’s Guide for DSA1000 Series
User interface legends (Continued)
NO. Name Description
25 Span or stop
frequency
The frequency range of current sweep channel can be
expressed by a combination of center frequency and
span or a combination of start frequency and stop
frequency.
26 Manual symbol Parameters non-auto coupling.
27 VBW Video bandwidth.
28 Spectrum line
area
For displaying spectrum line.
29 RBW Resolution bandwidth.
30 Center or starting
frequency
The frequency range of current sweep channel can be
expressed by a combination of center frequency and
span or a combination of starting frequency and stop
frequency.
31 Y scale Label of Y scale.
32 Parameter status I
cons on the left side of the screen indicate the status
of system parameters.
33 Detection type Pos peak, Neg peak, Sample, Normal, RMS Avg,
Voltage Avg and Quasi-Peak.
34 Trigger type Free, video and external.
35 Sweep mode Continuous or Single sweep (with current sweeping
times showing)
36 Correction switch Turn the Correction On or Off.
37 Signal tracking Enable or disable signal tracking.
38 Preamplifier
status*
Enable or disable the preamplifier.
39 Trace 1 types and
status
Trace types: Clear Write, Max Hold, Min Hold, Video
Avg and Power Avg.
Trace status: yellow denotes On, and gray denotes
Off.
40 Trace 2 types and
status
Trace types: Clear Write, Max Hold, Min Hold, Video
Avg and Power Avg.
Trace status: purple denotes On, and gray denotes
Off.
Note*: For DSA1030/DSA1030-TG only.
