ID Number Formats
Keypads, sirens, as well as expansion modules (bus zone expanders, zone
expanders, wireless expansion modules, utility output modules, power-supply
expansion modules) that are connected via a RISCO bus line display on the keypad
as per this example: 02(1:01) T=NZE08
EXPLANATION:
 02 is the index number of keypad, siren, or voice/expansion module
 1 is the RISCO bus line number that it is on
 01 is the sequential, installer-set physical ID number
 T (type) is NZE08 (8-Zone Expander)
System detectors and accessories (other than keypads, sirens and expansion
modules) have their zones display as per these examples:
 Bus detector connected via a bus zone expander: 4:B08:05
 Relay detector wired to a zone expander: 4:E08:05, or wired to a zone (1—8)
on the terminal block: 4:E00:05
 Input zone (relay detector wired directly onto a compatible type of bus device
(such as the iWISE Bus and Elegant keypad), which thereby shares its bus line
connection): 4:I08:05
 Wireless detector connected to a wireless expansion module: 4:W08:05
EXPLANATION (for all 4 examples above):
 4 is the RISCO bus line number
 The next value (for B08, E08, I08, or W08) is for the ID of the expansion
module or input zone that the detector is connected to (B = bus zone
expander, W = wireless zone expander, I = input zone, E = wired zone
expander)
 05 is the sequential, installer-set physical ID number
NOTES: [For main panel terminal block wiring]: For a bus zone expander wired
to a bus line at the terminal block, its ID will show as B00. For a relay detector
wired to a zone (1—8) at the terminal block, its ID will show as E00. For a UO
module wired to a UO terminal at the terminal block, its ID will show as 0x
(whereas x= zone number 1—6)
