Installation
Step 1: Creating a Plan for Mounting the System
NOTE: For main panel installation, see the box/enclosure instructions. See the
ProSYS Plus Installation and Programming Manual for wireless system mounting
considerations.
Main Panel Mounting Guidelines
Before you mount the main panel and peripheral components, make a plan for
obtaining the most optimal location for the panel, which (depending on
configuration-specific requirements) should typically be:
Centrally located for minimizing lengthy bus line/ expansion module wire runs
In a location with good GSM reception
In a secure location that is hidden and not reachable by those for whom use is
unintended (such as small children)
Near an uninterrupted 230 VAC electrical outlet, an easily-accessible disconnection
device such as a circuit breaker (if permanently connected to the electrical power
supply), grounding connection, and network cable outlet, as needed
In a dry place, away from sources of electrical and RF disturbance, and not near
large metal objects which may hinder reception
Step 2: Wiring, Settings, and Module Installations at
the Main Panel
Power Supply, Ground Wiring and Telephone Wiring
IMPORTANT: AC wiring should be performed by a certified electrician, and in
compliance with applicable electrical code, laws and regulation. See the ProSYS Plus
Installation and Programming Manual and the box/enclosure instructions. The electrical
power rating is specified on the label located next to the fuse.
The main panel should be connected to an easily-accessible wall outlet so that
electrical power can be disconnected immediately in case of malfunction or hazard. If
it is permanently connected to an electrical power supply, then the connection should
include an easily-accessible disconnection device, such as a circuit breaker
