09/2016 Page 52 5IN2371 C
INSTALLER PROGRAMMING
Step 1: Defining Additional Parameters in the Installer
Programming Menu
For additional system parameters (from the installer Programming menu), program
them as needed. See the ProSYS Plus Installation and Programming Manual.
Step 2: Exiting Installer Programming Menu after Initial
System Configuration
IMPORTANT: After programming at initial system setup from the installer
Programming menu, you must exit it. Then you can then program additional
parameters as needed from the other installer menus.
To exit installer Programming menu after initial system programming:
WARNING: In the main panel box/enclosure do not touch any AC electrical
wiring to/from the mains fuse terminals nor the mains fuse terminals, as 230 VAC
can result in electric shock and death.
1. With the main panel still powered up, carefully open the panel box / enclosure.
2. At SW1 on the PCB, carefully set DIP switch 2 to OFF.
3. Close the main panel box/enclosure in order to prevent a front tamper alarm.
4. Press on keypad repeatedly to go to the beginning of the current menu.
5. Press 0 to exit, toggle with to Y to save all your programming settings,
and then press ; TAMPER TESTING displays as the system checks for tamper
trouble conditions.
6. If an alarm sounds and you want to quit with a current tamper trouble
condition, press , press to toggle to Y (yes), and then press .
If you select N (no), you will not be able to exit Programming mode until the
tamper trouble condition has been restored to normal.
NOTE: After exiting the initial system setup programming, if you ever need to
access the installer Programming menu again, DIP switch 2 should remain in the
OFF position.
Step 3: Defining Parameters in other Installer Menus
After performing the Exiting Installer Programming Menu procedure, you can
access other installer menus to define parameters, as needed (see the ProSYS Plus
Installation and Programming Manual).
