Risco ProSYS Plus - Technical Specification

09/2016 Page 54 5IN2371 C
Technical Specification
Main Panel Technical Information
Input Power:
AC/DC Adaptor 100-240 V, 50/60Hz 14.4V
(+/-5%) —4A PS
Current Consumption: 110 mA, typical, 180 mA, maximum
Rechargeable Standby Battery: 12 V, 18 Ah (Amp-hours)
Output Voltage Range 11
V
—13.8V (ripple 200 mV)
Power Output
1. Maximum current draw from each bus (“AUX RED”
terminals is 750 mA
2. Maximum current draw from Bell/LS terminal is 750 mA
3. Maximum combined current draw from the two AUX
terminals, plus UO1 and UO2 is 750 mA
4. Total current draw from panel terminal blocks should not
exceed 2000 mA, in addition to above limitations
Programmable outputs:
UO1: Dry contact relay (24V, 1 Amp)
UO2: 500 mA transistor (Open Collector)
UO3 – UO4: 100 mA, opto relay
Main Box/Enclosure Dimensions
RP512BM21 375 x 330 x 98 mm
RP512BM26 420 x 379 x 95 mm
Operating temperature -10°C to 55°C (14°F to 131°F)
Keypads, Expansion Modules,
Communication Modules
Technical Information
Elegant Keypad (RPKEL) 12 V +
/
-15%, 100 mA maximum
Elegant Keypad—Proximity (RPKELP) 12 V +
/
-15%, 150 mA maximum
LCD Keypad (RP432KP) 13.8 V +
/
-10%, 48 mA typical, 52 mA maximum
Proximity LCD Keypad (RP432KPP) 13.8 V +
/
-10%, 62 mA typical, 130 mA maximum
Touchscreen Keypad (ProSYS KP) 13.8 V DC +
/
-10%; 30 mA typical, 180 mA maximum
Single Zone Expander (RP128EZ1) 13.8 V DC +
/
-10%; 20 mA
8 Zone Expansion Module (RP432EZ8) 20 mA, typical, 29mA maximum
16 Zone Expansion Module (RP512EZ16)20 mA typical, 100 mA maximum
Bus Zone Expander (RP128EZB) 20 mA
Wireless Expansion Module
(RP432EW8, RP432EW4)
13.8 V DC +/-10%; 40 mA typical, 65 mA maximum
4 x 3A relay output expansion module
(ProSYS E04)
13.8VDC +
/
-10%; 25 mA typical / 160 mA maximum
4 Form C (SPDT) Relays.; 5 A / 24V DC
8 x 100 mA Output Expansion Module
(ProSYS E08)
13.8VDC +/-10%; 25 mA typical / 70 mA maximum
[Italy] Prox. Key Reader (ProSYS PKR3) 13.8 V DC +
/
-10%; 70 mA, typical, 180 mA maximum
Digital Voice Module (RP432EV) 13.8 V DC +
/
-10%; 30 mA typical, 70 mA maximum
Listen & Speak Unit (RP128EVM) 7 V DC, 10mA standby, 60mA typical, 130 mA maximum
Plug-in single
-
socket GSM/GPRS
Module (RP432GSM)
13.8 V DC +
/
-10%; 30mA standby, 300mA communicating
Plug-in multi-socket 2G GSM Module
(RP512G2)
30 mA standby, 300 mA communicating
