09/2016 Page 39 5IN2371 C
Step 4: Allocating Wireless Zones
Multiple 1-way and 2-way wireless detectors and accessories are connected to the
system via wireless expansion modules – each of which supports multiple wireless
zones, and is connected to a RISCO bus line or at the main panel PCB.
Allocating Wireless Expanders
Wireless expanders must be allocated before their respective detectors/accessories.
To allocate wireless expanders:
1. From the installer Programming menu, go to 7 > 1 > 2 > 0 > 5 (Install >
Bus Device > Manual > WL Expander).
2. Scroll to, and then edit the WL expander’s physical ID number to match its DIP
switch settings (see Describing Installer-Set ID Numbers for Bus Devices, page 18).
3. Press to toggle between WM (to enable the Wireless Expander module) or
select NONE (to cancel its allocation), and then press OK ( ).
4. Define whether to bypass the wireless expander box tamper, using to
toggle between Y (to bypass) and N, and then press .
Allocating Wireless Devices
Each wireless transmitting device must be allocated (via keypad or Configuration
Software) by either sending an RF transmission (see below), or by entering the
device’s 11-digit code (see the ProSYS Plus Installation and Programming Manual).
To allocate wireless devices via RF transmission (from Elegant keypad):
1. From the installer Programming menu, go to 7> 2> 2> 1 > 1
(Install > WL Device > Allocation >By RF > Zone).
2. If you have multiple wireless receivers, scroll to the first one for which you want
to allocate it’s wireless devices, and then press OK ( ); Each zone appears in
one of the following formats: “Select (—:———:——)” which indicates the
zone is available for allocating, or “Select (3:E02:06)” which, in this example,
indicates the zone has already been allocated.
NOTE: If you try to allocate the same wireless zone number twice, the second
allocation will re-write (cancel) the prior allocation.
3. Scroll to the zone number you want to allocate (or enter the zone number using
3 digits – for example enter 022 for zone 22), and then press ; the wireless
expander is now in “learn” mode for the next 180 seconds.
4. Per the table below, within the remaining time, send an RF transmission from a
wireless device that you want to sync with the selected wireless expander. If
“write message not found” displays, it means the transmission was not received
and the device didn’t get allocated.
