Risco ProSYS Plus - Zone Expanders; Utility Output Modules; Power Supply Modules

09/2016 Page 35 5IN2371 C
Zone Expanders
1. From the installer Programming menu, select 7> 1> 2, scroll to 02) Zone
Expand., and then press OK ().
2. Scroll to, and then edit the zone expander’s physical ID number to match its DIP
switch settings (Describing Installer-Set ID Numbers for Bus Devices, page 18).
3. Press to toggle to the type (NZE08 for an 8-zone expander, or NZE16 for a
16-zone expander), or select NONE to cancel its allocation, then press .
4. Select the zone termination resistance if applicable by scrolling to the correct
resistor values (in ohms), then press to advance to the next zone expander.
5. Repeat from step 2 for all additional zone expanders.
Utility Output Modules
1. From the installer Programming menu, select 7> 1> 2, scroll to 03) Util. Output,
and then press OK ().
2. Scroll to, and then edit the module’s physical ID number to match its DIP switch
settings (see Describing Installer-Set ID Numbers for Bus Devices, page 18).
3. Press to toggle to the UO type (or select NONE to cancel its allocation),
and then press .
Power Supply Modules
1. From the installer Programming menu, select 7> 1> 2, scroll to
04)Power Supply, and then press OK ( ).
2. Scroll to, and then edit the PS module’s physical ID number to match its DIP
switch settings (see Describing Installer-Set ID Numbers for Bus Devices, page 18).
3. Press to toggle to the PS type (or select NONE to cancel its allocation), and
then press .
4. Select the partition number(s) for the power supply module. While scrolling
through each block of partitions, designate the partition(s) to allow operation
via the keypad. Enter a partition number to select it (it will display), or enter the
number again to clear it (it will not display).
5. Press ; 1)BELL/L.SPEAK N displays
6. Press to toggle between Y (yes) or N (no) for enabling or disabling the
bell / loudspeaker, and then press .
7. Repeat from step 2 for all additional power supply modules.
