09/2016 Page 38 5IN2371 C
3. Scroll to and then edit the bus detector’s physical ID number to match its DIP
switch settings (see Describing Installer-Set ID Numbers for Bus Devices, page 18).
4. Press to toggle to the correct bus zone type (or select NONE to cancel its
allocation), and then press ; “Link Bus Input to Zone ###?” displays (whereas
### is the zone number).
5. To link (enable), use to toggle to Y, and then press .
6. Repeat this procedure for all additional bus detectors.
Bus Zone Expanders
1. From installer Programming menu, go to: 7>1>2>13 (Install > Bus Device >
Manual > Bus Expander); the first BZE (Bus Zone Expander) displays. See
Describing Installer-Set ID Numbers for Bus Devices, page 18 for a description of
the displayed BZE format.
2. Scroll to, and then edit the BZE’s physical ID number to match its DIP switch
settings (see Describing Installer-Set ID Numbers for Bus Devices, page 18).
3. Press to toggle to the type (or select NONE to cancel its allocation), then
press OK ().
4. Repeat from step 2 for all additional BZEs.
