2-30 Riverstone Networks RS 3000/3100/3200 Switch Router Getting Started Guide
Hardware Features Introduction
Riverstone offers four cables, listed in Table 2-22, used to connect the RS 3000, RS 3100 and RS 3200 to standard
CSU/DSU connectors.
The Dual Serial and Quad Serial – C/CE line cards use the following LEDs.
13 P2_RXD_A 28 P1_DSR_B 43 P2_DTR_A 58 P1_DTR_B
14 P2_RXC_B 29 P1_MODE[1] 44 P2_SCTE_B 59 P1_LL_A
15 P2_RXC_A 30 P1_GND 45 P2_SCTE_A 60 P1_SHIELD
Table 2-22 Riverstone dual serial port to CSU/DSU connector cables
Riverstone Part Number CSU/DSU Connector Type Standard
RS-V35DTE-02 Two (2) V.35 34-pin connectors
a
V. 3 5
RS-530DTE-02 Two (2) DB-25 25-pin connectors EIA-530
RS-449DTE-02 Two (2) DB-37 37-pin connectors RS-449
RS-X21DTE-02 Two (2) DB-15 15-pin connectors X.21
a. The two remote ends of each type of connector cable is labeled “Port A” and “Port B”. “Port A”
corresponds to Port 1 on a Dual Serial WAN line card and Port 1 or 3 on a Quad Serial – C/CE, depending
upon which WAN line card port you are using. Similarly, Port B corresponds to Port 2 on a Dual Serial WAN
line card and Port 2 or 4 on a Quad Serial – C/CE.
Table 2-23 Dual Serial and Quad Serial – C/CE WAN line card LEDs
LED Description
Per-port Link Indicates that the line card detects a cable and a good link is established.
Per-port Rx Indicates when the port’s transceiver receives data.
Per-port Tx Indicates when the port’s transceiver transmits data.
Table 2-21 LFH-60 connector pinouts (Continued)
Pin Signal Pin Signal Pin Signal Pin Signal
