Riverstone Networks RS 3000/3100/3200 Switch Router Getting Started Guide 2-41
Introduction Hardware Features
Note When the GIC-12 GBIC is plugged into a port, the link LED for the line card is lit
even when there isn’t a cable plugged into the GBIC.
When the GIC-12 GBIC is plugged into a port, autonegotiation should be set for
that port.
The Advanced Services line card uses the LEDs as described in Table 2-38.
Table 2-37 GBIC modules media specification
Port type Specification
GBIC SX (MMF)
• Multi-mode fiber interface
• 50 or 62.5 125-mm multi-mode fiber cable
terminated with SC connectors
• Maximum of 300 m of cable
GBIC LX (SMF-IR)
• Single-mode fiber (intermediate range) interface
• 8 or 9 125-mm single-mode fiber cable terminated
with SC connectors
• Maximum of 10 km of cable
GBIC LH (SMF-LR)
• Single-mode fiber (long range) interface
• 8 or 9 125-mm single-mode fiber cable terminated
with SC connectors
• Maximum of 70 km of cable
GIC-12
• Twisted pair copper with RJ-45 interface
• Conforms to all 1000 BaseT specifications
GIC-CWDM
• See Section 2.4.7, "CWDM GBICs" for details about
using CWDM GBICs with this line card.
Table 2-38 Advanced Services line card LEDs
LED Description
Online When lit, this green LED indicates that the line card is online and is ready to receive, process,
and send packets if configured to do so.
