Riverstone Networks RS 3000/3100/3200 Switch Router Getting Started Guide 3-19
Hardware Installation Installing the Hardware
Table 3-4 Wiring map for MDI management cable
Signal (RS 3000 port) Pin Signal (management console port)
TXD (transmit data) 1 RXD (receive data)
a
TXD (transmit data) 2 RXD (receive data)
RXD (receive data) 3 TXD (transmit data)
Unused 4 Unused
Unused 5 Unused
RXD (receive data) 6 TXD (transmit data)
Unused 7 Unused
Unused 8 Unused
a. The right hand column pin assignments are for the RJ-45 connector on the RS 3x00. Pin 1 (TXD or “transmit data”)
must emerge on the management console’s end of the connection as RXD (“receive data”).
