3 Web Interface
Gain For 4-20mA sensors:
Gain = (Sensor high range value – sensor low range value) ÷ 3085
Example: Temperature sensor with a sensing range of 5-120°F
Gain = (120 - 5) ÷ 3085 = 0.0373
For 0-5V and 0-10V sensors:
Gain = (Sensor high range value – sensor low range value) ÷ 3856
Example: Temperature sensor with a sensing range of 5-120°F
Gain = (120 - 5) ÷ 3856 = 0.0298
Offet For 4-20mA sensors:
Offset = Sensor low range – ((Sensor high range value – sensor
low range value) ÷ 4)
Example: Temperature sensor with a sensing range of 5-120°F
Offset = 5 - ((120-5) ÷ 4) = -23.75
For 0-5V and 0-10V sensors:
Offset = Sensor low range
Example: Temperature sensor with a sensing range of 5-120°F
Offset = 5
Footer Buttons - Remember to click the Submit Changes button for the sensor you’re
currently configuring before you move to another sensor’s configuration page.
<Previous Sensor Configure the previous sensor in the list.
Next Sensor> Configure the next sensor in the list.
Option Description
Table 3.4 Individual Sensor Page - Sensor Configuration Tab Options
