AX10 Palletizing Solution
Cable Management System
Cable Management with Generic Gripper
If the PowerPick10 Vacuum Gripper is not part of the scope of delivery along with the AX10, the following components are
provided for the cable management of a generic gripper.
l
4x cable clips + 0.5 m hook and loop (VELCRO®) fastener
l
8 x 190 mm cable ties
Cable management with PowerPick10 Vacuum Gripper (optional)
When mounting a Robotiq PowerPick10 Vacuum Gripper on the AX10 Palletizing Solution, the following components are provided
for the cable management system.
l
4 x cable clips + 0.5 m hook and loop (VELCRO®) fastener
l
1 x tubing curler
l
1 x mm double air tube (3 m length)
l
14 x 190 mm cable ties
1. Gripper Mounting
l
Mount the Gripper on the tool flange.
NOTICE
For more information on how to install the PowerPick10 Vacuum Gripper, please refer to the
Mechanical Installation section of the PowerPick10 user manual available at robotiq.com/support.
