AX10 Palletizing Solution
NOTICE
Patterns are specific to recipes, meaning that two distinct recipes can each be composed of patterns
that are named identically.
Pattern Editing Menu
This interface includes a representation of a pallet.
The user can use the controls on the screen to fill the virtual pallet layer in the most efficient manner possible.
NOTICE
What can be called the origin (0,0) in the pallet diagram is actually the top left corner of the pallet.
And so, since the user can modify the coordinates of the active box, going left to right increases the X
value, and going top to bottom increases the Y value.
NOTICE
l
A light blue box is a box that has been placed. It can be selected by tapping on it.
l
The dark blue box is the active box. It can be moved around using the arrows on the screen.
l
A red box is an "overlapping box."
l
Multi-pick feature: Boxes that are part of the active box type are shown in light blue (including the
active box, in dark blue); boxes that are not part of the active box type are shown in grey.
99
