ROCAMED MH01 - Alarm - Fiber Consumption; Laser Parameters

43
NOTE-MH01-EN rev05
NOTE: If the footswitch is left unused for a long time in READY mode the laser device will
enter automatically the STANDBY mode.
5.5.6 Alarm - fiber consumption
When this signal appears please move the
system in standby and refurbish the tip of
the fiber (cap 7.6).
The signal disappears automatically after
few seconds or if the operator touch the
screen.
5.5.7 Laser Parameters
The following tables give indication of maximum laser output for each possible combinations
(Power=Energy*Frequency).
The size of the fiber has to be taken in consideration to detect power limits
For all fiber dimension*
LITHOTRIPSY – Fragmentation
200
mJ
300
mJ
400
mJ
500
mJ
600
mJ
700
mJ
800
mJ
1 J
1.2 J
1.5 J
1.8 J
2 J
2.5 J
3 J
3.5 J
4J
3 Hz
1,5
W
1,8
W
2,1
W
2,4
W
3
W
3,6
W
4,5
W
5,4
W
6
W
7,5
W
9
W
10,5
W
5 Hz
2,5
W
3
W
3,5
W
4
W
5
W
6
W
7,5
W
9
W
10
W
12,5
W
15
W
17,5
W
20
W
8 Hz
4
W
4,8
W
5,6
W
6,4
W
8
W
9,6
W
12
W
14,4
W
16
W
20
W
24
W
10 Hz
5 W
6 W
7 W
8 W
10 W
12 W
15 W
18 W
20 W
25 W
30 W
12 Hz
6
W
7,2
W
8,4
W
9,6
W
12
W
14,4
W
18
W
21,6
W
24
W
30
W
15 Hz
7,5
W
9
W
10,5
W
12
W
15
W
18
W
22,5
W
20 Hz
10 W
25 Hz
5
W
7,5
W
10
W
For all fiber dimension*
LITHOTRIPSY – Dusting
200
mJ
300
mJ
400
mJ
500
mJ
600
mJ
700
mJ
800
mJ
1 J
1.2 J
1.5 J
1.8 J
2 J
2.5 J
3 J
3.5 J
3 Hz
5 Hz
2,5
W
3
W
3,5
W
4
W
5
W
6
W
7,5
W
9
W
10
W
12,5
W
15
W
8 Hz
4
W
4,8
W
5,6
W
6,4
W
8
W
9,6
W
12
W
14,4
W
16
W
20
W
10 Hz
5 W
6 W
7 W
8 W
10 W
12 W
15 W
18 W
20 W
25 W
12 Hz
6
W
7,2
W
8,4
W
9,6
W
12
W
14,4
W
18
W
21,6
W
24
W
15 Hz
7,5
W
9
W
10,5
W
12
W
15
W
18
W
22,5
W
20 Hz
10
W
25 Hz
