10 TECHNICAL SPECIFICATIONS
10.1 General specification
Product category
Surgical laser for medical use
Classification according to Medical Device
Directive 93/42/EEC
Class IIb
Laser Classification according to Class 4 IEC
60825-1:2014
Class 4
Aiming Beam classification according to IEC
60825-1:2014
Class 3R
Electrical requirements
100-120 Vac; 50/60 Hz; 16A
200-240 Vac; 50/60 Hz; 10A
Degree of protection against the ingress of
liquid (IEC529)
IP20
Type of protection against electric shock
Class I
Type of applied parts
BF
Dimensions
332 (W) X 967 (D) X 938 (H) mm
Weight
60kg
Operation temperature
10°C - 30°C
Storing temperature
5°C - 40° C
Relative Humidity
from 30% to 85% (no condensing)
Atmospheric Pressure
800-1060 hPa
Cooling system
Air cooled (closed water-air cooling circuit)
10.2 Laser source specification
Laser Type
Flashlamp Pumped Ho:YAG
Wavelength
2.1µm
Power to tissue
30 Watts
Energy/pulse
0.2÷4J
Application mode
Pulsed
Time function
Single pulse; Pulse sequence
Pulse Width
150 - 850µs
Repetition rate
3-25 Hz
Delivery Device
Wide range of flexible silica frontal fiber
(sterile and reusable)
Aiming Beam
Diode laser, green, 532nm (<5mW,
adjustable by software)
Results of MPE, NOHD and OD calculations are reported in the table below:
Wavelength
2100 nm
Divergence
440 mrad
Exposure time
100 s
MPE
1000 W/m
2
NOHD
0.44 m
OD
2
