Rockwell Automation Publication KNX-SG001H-EN-P - December 2020 23
Product Features Comparison
Kinetix VP Servo Motors (continued)
Motor Features Kinetix VPF Food-grade Motors Kinetix VPH Hygienic Stainless-steel Motors Kinetix VPS Stainless-steel Motors
Main characteristics
• Developed to match Kinetix 5500 drive and
Kinetix 5700 dual-axis inverter
• Configurable winding options, brakes, and encoder
feedback
• ratings for optimized system sizing
• 2090-Series single-cable technology
• Low rotor inertia
• Design per EHEDG guidelines for smooth surface
and liquid collection. For use with high-pressure,
highly-caustic washdown applications.
• 2090-Series single-cable technology
• Hiperface DSL encoder protocol
• Low rotor inertia
• Developed to match Kinetix 5500 drive and
Kinetix 5700 dual-axis inverter
• Specifically designed for sanitary environments
for use with high-pressure, highly-caustic
washdown applications
• 2090-Series single-cable technology
• Low rotor inertia
Features
• Food-grade epoxy coating
• 200 and 400V-class windings
• Single-turn and multi-turn absolute feedback
• SIL 2 (PLd) rated encoder options
• Shaft end threaded hole
• SpeedTec DIN connector, rotates 315°
• High-energy rare-earth magnets
• Standard IEC 72-1 mounting dimensions
• Smooth, passivated, 316 grade stainless-steel
cylindrical exterior
• Designed per EHEDG guidelines
•3A certified
• Certified and listed to NSF/ANSI Standard 169
• 200V and 400V-class windings
• Single-turn and multi-turn absolute feedback
• SIL 2 (PLd) rated encoder options
• Shaft-end threaded hole
• On-motor cable extensions available in 1…15 m
(3.2 …49.2 ft) lengths with connector and flying-
lead options
• High-energy rare-earth magnets
• Standard IEC 72-1 mounting dimensions
• Smooth, passivated 300 series stainless-steel
cylindrical exterior
•Complies with NSF/ANSI Standard 169
• 400V-class windings
• Shaft-end threaded hole
• Cable extended 5 m (16.4 ft) from motor to protect
connector
• Standard IEC 72-1 mounting dimensions
Motor type Brushless AC synchronous servo motors Brushless AC synchronous servo motors Brushless AC synchronous servo motors
Environmental ratings
• IP66/IP67 with shaft seal (standard)
(1)
• Food grade grease on shaft seal
(1) IP66/IP67 with shaft seal (standard) and the use of Rockwell Automation factory-delivered 2090-Series single cable.
• IP66/IP67 with shaft seal (standard)
(1)
•IP69K
(2)
• IP66/IP67 with shaft seal (standard)
(1)
•IP69K
(2)
(2) IP69K for 1200 psi motor washdown with shaft seal (standard), not including on-motor cable connector.
Continuous stall torque 0.93…19 N•m (8…172 lb•in) 0.80…19 N•m (7…165 lb•in) 8.1 and 21.0 N•m (72 and 186 lb•in)
Peak stall torque 2.69…49 N•m (24…430 lb•in) 2.76…67.8 N•m (24…600 lb•in) 27.1 and 67.8 N•m (240 and 600 lb•in)
Rated speed Up to 8000 rpm 2300…8000 rpm 3000 rpm
Motor rated output 0.34…4.18 kW (0.46…5.60 Hp) 0.40…3.16 kW (0.54…4.23 Hp) 1.4 and 3.3 kW (1.9 and 4.4 Hp)
Feedback options
• Multi-turn, high-resolution absolute position
• Single-turn, high-resolution absolute position
Multi-turn, high-resolution absolute position
Motor options
•24V DC brake
•Shaft seal kit
• Positive air-pressure kit
•24V DC brake
•Shaft seal kit
• Positive air-pressure kit
• Mounting plate O-ring
• Shaft seal kit with slinger
•Positive air-pressure kit
Compatible drives
• Kinetix 5700
• Kinetix 5500
•Kinetix 5700
•Kinetix 5500
• Kinetix 5700
• Kinetix 5500
Servo cable
compatibility
• 2090-CSxM1xx-xxAA/AFxx (TPE) cables
• 2090-CSxM1xx-xxVA/LFxx (PVC and PUR) cables
• 2090-CSxM1xx-xxAA/AFxx (TPE) cables
• 2090-CSxM1xx-xxVA/LFxx (PVC and PUR) cables
• 2090-CSxM1xx-xxAA/AFxx (TPE) cables
• 2090-CSxM1xx-xxVA/LFxx (PVC and PUR) cables
Typical applications
•Food packaging
• Volumetric filling
• Form, fill, seal
• Food handling
• For meat and poultry applications, the stainless-
steel motors are recommended
• Meat, poultry, dairy, food and beverage processing
• Food slicing and filling
• Raw food handling
• Life science
•Consumer products
• Meat and poultry processing
• Food slicing and filling
• Raw food handling
• Life science
•Consumer products
