Detector System - Components
This manual describes all major components of the RoentDek delay-line detector system as it can be delivered for the
DLD40(EP), DLD80(75eT), HEX80/HEX75 and DLD120 and HEX120(100) detector. Even if you have not purchased
the complete system you will find valuable information in the chapters describing the different components about the link
between the components and the operation. However, you might have received only the relevant parts of this manual.
1. DLD or HEX microchannel plate detector with delay-line anode
0. FT12(16)TP 12-pin CF35 (and fourfold MHV) UHV-feedthrough flange(s) with signal decouplers and (optional)
flange mounting gear on DNxxxCF flange with CF35 ports (xxx = 100 – 300)
0. ATR19 fast (differential) amplifier unit with integrated constant-fraction-discriminator (default) or
FAMP8 (or similar) amplifier unit, CFD8c/7x: (or similar) constant-fraction-discriminator modules (for download)
0
. TDC8HP or HM1 time to digital converter and
read-out software (default) or
fADC4/8 fast ADC units (for download)
Error! Reference source not found.. HV2/4, BIASET3 or similar high voltage supply assembly and
BA3/HVT/HVZ auxiliary bias units.
Please follow the link http://www.roentdek.com/manuals
for device specific manuals.
If you have received special detector components, i.e. a detector of different size or type, or other electronic modules you will
find a separate manual commenting on peculiarities of your special system. In this case the information given here is mostly
relevant for your system but you might need extra information. Please also refer to the FAQ document on the web page.
Please always check our web site for updates after you have received our products or contact
RoentDek.
MCP Delay Line Detector Manual (11.0.1304.1) Page 5 of 83
