Rohde & Schwarz CMU200 Service Manual

R&S PB Installation Instruction CMU-B41 AUDIO-GEN.+ANA. Bi/1CMK 18.11.99 1100.5397.00 02.00
page 3 of 7
½ After undoing two countersunk head screws at the top left frame, raise cover slightly, push somewhat to
the right and take it off towards the top
Fig. 2
COUNTER HEAD SCREWS
COVER

Rohde & Schwarz CMU200 Specifications

General

Brand	Rohde & Schwarz
Model	CMU200
Category	Test Equipment
Language	English
