Measuring Instruments and Auxiliary Equipment
Table 1-1 Measuring instruments and auxiliary equipment for manual performance test
Item Type of instrument Required characteristics Appropriate device R & S order
number
Use
1 Signal generator 100 kHz to 2.7 GHz,
Generation of a GSM signal
(dummy burst)
SME03
SMIQ
1038.6002.03 RX measurements
2 Spectrum analyzer 100 kHz to 7 GHz,
Demodulation of GSM signals
FSE with FSE-B7
FSIQ
FSP–3
1066.30.10.20
1066.30.10.30
1066.4317.02
1093.4495.03
TX measurements
3 Power meter NRVD with sensors
NRV-Z4
NRV-Z51
RX measurements,
TX measurements
4 Power amplifier 100 kHz to 2.7 GHz,
Pout = 100 W
RX measurements
5 Harmonics filter attenuate the harmonics of the
power amplifiers to min 30 dBc
RX measurements
6 Directional coupler 50 MHz to 2.7 GHz,
up to 100 W
RX measurements
7 Network analyzer
or VSWR Bridge
100 kHz to 2.7 GHz ZVR
ZRC
1043.0009.61 Reflection coefficient/
VSWR
RF connectors
