R&S PB Installation Instruction CMU-U53 BLUETOOTH_F.CMUBi/1CMK 08.09.00 1100.7383.00 01.00
page 3 of 11
After undoing two countersunk head screws at the top left frame, raise cover slightly, push somewhat to the
right and take it off towards the top.
COUNTERSUNK HEAD
SCREWS
COVER
Fig. 2
