Rohde & Schwarz CMU200 Service Manual

Test Report CMU
1100.4903.82 1.24 E–4
Item
No.
Description
Measure-
ment to
section
Min. Actual Max.
Measurement
uncertainty
Unit
TX fixed spurious,
CMU setting = 1800 MHz
search freq. 842.08 MHz
Level = +10 dBm
–40 dBc
TX fixed spurious,
CMU setting = 1800 MHz
search freq. 1684.16 MHz
Level = +10 dBm
–40 dBc
TX fixed spurious,
CMU setting = 1800 MHz
search freq. 2642.08 MHz
Level = +10 dBm
–40 dBc
TX fixed spurious,
CMU setting = 1900 MHz
search freq. 842.08 MHz
Level = +10 dBm
–40 dBc
TX fixed spurious,
CMU setting = 1900 MHz
search freq. 1057.92 MHz
Level = +10 dBm
–40 dBc
TX fixed spurious,
CMU setting = 1900 MHz
search freq. 1684.16 MHz
Level = +10 dBm
–40 dBc
TX fixed spurious,
CMU setting = 1900 MHz
search freq. 2742.08 MHz
Level = +10 dBm
–40 dBc
TX fixed spurious,
CMU setting = 2199 MHz
search freq. 842.08 MHz
Level = +10 dBm
–40 dBc
TX fixed spurious,
CMU setting = 2199 MHz
search freq. 1356.92 MHz
Level = +10 dBm
–40 dBc
TX fixed spurious,
CMU setting = 2199 MHz
search freq. 1684.16 MHz
Level = +10 dBm
–40 dBc
TX fixed spurious,
CMU setting = 2199 MHz
search freq. 3041.08 MHz
Level = +10 dBm
–40 dBc
TX SSB Phase Noise
TX SSB phase noise
f = 100 MHz, ∆f = 20 kHz
TX SSB
phase noise
–100 dBc
TX SSB phase noise
f = 100 MHz, ∆f = 250 kHz
–110 dBc
