Rosco CSV User Manual

Rosco CSV Variable Width Chip Spreader 6-75
Schematics
HYDRAULIC MANIFOLD - MAIN CONTROL, FA (1 OF 4)
Schematic #1016206
Figure 6-37. Hydraulic Manifold - Main Control, FA (1 of 4)
CB2CB1
FD
2800
PSI
125
PSI
PC6PC5
PC4
PC3
PC2
OR2 OR3 OR4 OR5
OR6
250
PSI
RV2
SV6SV5SV4SV3SV2
1000 PSI
PR2FR
RV1
PR1
SV1
BR-G BR
WA1
WA2
WB1 WB2
SS1A SS1B SS2A SS2B HB HA LA
LS1
PO
LPO
GL
TR
G P T
LS
PARK BRAKE
WINGS
SEAT SLIDE #1 SEAT SLIDE #2 HITCH UP/DOWN HITCH LATCH
2000 PSI
2000 PSI
NOTES:
PORT SIZES:1.
SAE-24: T, TR
SAE-20: P, PO
SAE-08: LPO
SAE-06: BR, BR-G, G, GL, HA, HB, LA,
LS, LSI, SS1, SS2, WA, WB
COIL SPECIFICATIONS:2.
VOLTAGE: 12 VDC
TERMINALS: DEUTSCH DT04-2P
