Rosco CSV Variable Width Chip Spreader 6-79
Schematics
HYDRAULIC MANIFOLD - WORK 2, FA (3 OF 4)
Schematic #1016205
Figure 6-39. Hydraulic Manifold - Work 2, FA (3 of 4)
PLG
CB2CB1
CV6
CV5
CV4
CV3
CV2CV1
SV3
FC2
SV2
SV1
FC1
PR1
GMG GM2 VS2 VS2R AM2 AM2R G2A G2B
LS
P
LP
T
500 PSI
10 GPM
6 GPM
3000 PSI 3000 PSI
100 PSI
PG
NOTES:
PORT SIZES:1.
SAE-06: GMG, LS, PG, PLG
SAE-08: VS2, AM2, G2A, G2B, LP
SAE-10: GM2, VS2R, AM2R
SAE-16: P
SAE-20: T
COIL SPECIFICATIONS:2.
VOLTAGE: 12 VDC
TERMINALS: DEUTSCH DT04-2P
To Next Page
