Rosco CSV - Hydraulic Hose Schedule - Secondary

Illustrated Parts List (IPL)
Rosco CSV Variable Width Chip Spreader7-126
HYDRAULIC HOSE SCHEDULE - SECONDARY
Hose
No.
Qty. Part Number Description
GRP 1015304 SEONDARY MANIFOLD HOSE KIT
85 1 P797TC0639202020-38.25 PROPEL PUMP B TO MOTOR A
86 1 P797TC0639202020-52.25 PROPEL PUMP A TO MOTOR B
87 1 K811HT0619404040-74 AUX PUMP SUCTION TO TANK
88 1 F387TC0637202020-40 AUX PUMP TO MAIN MANIFOLD P
89 2 F387TC9292060606-32-AS-B-13-29.5 FRONT AXLE STEER LINES
90 1 F387TC0692060606-176.5-AS-B-13-36 LEFT STEER TO TEE
91 1 F387TC0692060606-203.5-AS-B-13-36 RIGHT STEER TO TEE
