Item
No.
Part Number Qty. Description Remarks
1 1004985-01 1 Alternator, Cummins
2 1012526-27 1 Bracket, Alternator, Top
3 1012526-28 1 Bracket, Alternator, Bottom
4 1012526-29 1 Pulley, Alternator
5 1012526-23 1
Pulley, Fan Belt, 6.7L
6 1012526-22 1 Pulley, Tensioner, 6.7L
7 1012526-21 1 Water Pump, 6.7L
8 1012526-07 1 Belt, V-Ribbed, Serpentine, Rosco CSV
9 1012526-30 1
ECU, 6.7L
10 1012526-33 1 Filter Head, Fuel Water
11 1013667-18 1 Filter, Fuel/Water Separator
12 1011263-10 1
Element, Fuel Filter, 4.5 QSB, T4
13 1012526-31 1 Cover, Auxiliary Pump Mount
14 1012526-32 1 Hose, Fuel Supply
15 988693 1 Drive, Pump, SAE D, 27 Tooth
16 1013667-03 1 Valve, Coolant, Cummins
REF 129-#10-32-8 2 Machine Screw, HH, #10-32 x .50 Not Shown, Mounting #16
REF 302-#10 2 Washer, Lock, #10 Not Shown, Mounting #16
REF 300 2 Washer, Flat, SAE, #10 Not Shown, Mounting #16
17 1014840 1 Plate, Brace, Coolant Control
REF
100-M8-1.25-16-8.8F 2 CSHH, M8x1.25 x 16, C8.8, FT Not Shown, Mounting #17
REF 302-M8 2 Washer, Lock, M8 Not Shown, Mounting #17
REF 300-M8 2 Washer, Flat, SAE, M8 Not Shown, Mounting #17
18 1012526-26 2 Cap, Oil, Fill, Valve Cover
19 1008650-01 1
Starter, Denso PA90L, 4.8KW
20 1012526-16 1 Turbo, Mid Mount, Front Out, 6.7L
21 988666-03 1 Element, Oil Filter, 4.5 SQB
22 109740 1 Battery Disconnect
REF 33146-6 2 Battery, 12V, 1050 CCA Not Shown
REF 1015651 1
Cable, Battery, Positive, 17.25” Post/Post, 6 Not Shown
REF 1015660 1 Cable, Battery, Negative, Rosco CSV Not Shown
REF 36339 1 Cable, Battery, Negative, 17”, Eye/Eye, 1/0 GA B Not Shown
REF 986801 1 Cable, Battery, Positive, 42”, 2/0 GA Not Shown
23 100-6-16-20-5F 2
CSHH, 3/8-16 x 1.25, GR5, FT
24 302-6 2 Washer, Flat, SAE, 3/8
Engine Assembly - Engine Components
7
Illustrated Parts List (IPL)
Rosco CSV Variable Width Chip Spreader 7-19
