Item
No.
Part Number Qty. Description Remarks
1 1014571 1 Manifold, Main Control Includes 2 - 18, See Notes
2 1016206-15 1 Solenoid Valve, 2 Pos/3 Way, 1-3/1-2
3 986972-02 1 Coil, 12VDC Deutsch, Male Pins
4 1014571-08 1 Solenoid Valve, 3 Pos/4 Way, Motor Spool
5 1014571-11 1 Coil Spacer
6 1005448-02 1 Coil, 12VDC Deutsch, P Series
7 1016206-16 3 Solenoid Valve, 3 Pos/4 Way, Motor Spool
8 1014571-10 3 Coil Spacer
9 1001686-03 3 Coil, 12VDC Deutsch, J Series
10 1014569-01 10 Check Valve, Poppet Style
11 1014571-02 1 Solenoid Valve, 2 Pos/3 Way
12 1014571-12 1 Coil, 12VDC Deutsch
13 1016206-12 1
Press. Reducing/Relieving Valve
14 1014571-04 6 Check Valve, Pilot Operated
15 988696-20 1 Relief Valve, Direct Acting, Poppet Style
16 1014571-03 1
Press. Reducing Valve
17 1016206-08 1 Relief Valve, PO Spool Type, 80 GPM Max
18 1014571-01 1 Press. Compensated Flow Control, 0.1 GPM
Hydraulic - Manifold, Main Control - SS
NOTES:
1. Ensure the correct manifold manufacturer before ordering parts.
2. See Figure 6-33 for manifold schematic.
7
Illustrated Parts List (IPL)
Rosco CSV Variable Width Chip Spreader 7-23
