Item
No.
Part Number Qty. Description Remarks
1 1014568 1 Manifold, Auxiliary Function 1 Includes 2 - 14, See Notes
2 1014569-06 1 Proportional Directional Valve, D03, 12VDC
3 1002308-10 2 Directional Valve, D03, 12VDC Deutsch
4 1014568-01 2 Press. Compensated Proportional Flow Control
5 1014569-07 3 Coil, 12VDC Deutsch, 3A
6 1014569-03 1 Proportional PSI Comp. NC Flow 1-2 Spool
7 1016183-02 1 Press. Compensated Flow Control
8 1016183-05 1
PO Press. Reducing/Relieving Valve, 100-1000 PSI
9 1014569-02 1 Solenoid Valve, NC
10 1001686-03 1 Coil, 12VDC Deutsch, J Series
11 1014569-01 11 Check Valve, Poppet Style
12 1014569-04 2 Counterbalance Valve
13 1014569-05 3 Press. Compensated Flow Control
14 1016183-04 4 Check Valve, Pilot Operated
Hydraulic - Manifold, Work 1 - SS
NOTES:
1. Ensure the correct manifold manufacturer before ordering parts.
2. See Figure 6-34 for manifold schematic.
7
Illustrated Parts List (IPL)
Rosco CSV Variable Width Chip Spreader 7-25
