Item
No.
Part Number Qty. Description Remarks
1 1014570 1 Manifold, Steer, Brake, Fan Includes 2 - 14, See Notes
2 121584 1 Relief Valve, PO Spool Type, 30 GPM Max
3 1016207-07 1 Logic Element, Priority On Demand
4 1016207-09 1 Solenoid Valve, 2 Pos/4 Way, Pressure Crossover
5 984657-06 1 Coil, 12VDC Deutsch
6 1016207-06 1 Unloading Direct Acting Internal Pilot
7 1014570-02 1 Proportional PSI Comp NO Flow, 1-2 Spool
8 1014570-05 1 Coil, 12VDC Deutsch
9 1014570-03 1 Relief Valve, Direct Acting Poppet, 10 GPM Max
10 987322-16 1 Solenoid Valve, 2 Pos/3 Way
11 1001686-03 1 Coil, 12VDC Deutsch, J Series
12 1014570-04 2 Check Valve, 3 PSI Spring
13 1016207-03 1 Check Valve, 30 PSI Spring
14 10162074-01 3 Shuttle Valve
Hydraulic - Manifold, Brake/Steer/Fan - SS
NOTES:
1. Ensure the correct manifold manufacturer before ordering parts.
2. See Figure 6-36 for manifold schematic.
7
Illustrated Parts List (IPL)
Rosco CSV Variable Width Chip Spreader 7-29
