Item
No.
Part Number Qty. Description Remarks
1 1016206 1 Manifold, Main Control Includes 2 - 19, See Notes
2 1016206-18 1 Cartridge, Flow Regulator, .10 GPM
3 1016206-17 1 Cartridge, 4W/3P Solenoid, Float Center
4 1005448-02 2 Coil, 12VDC Deutsch, P Series
5 1016206-16 3 Cartridge, 4W/3P Solenoid, Float Center
6 1001686-03 6 Coil, 12VDC Deutsch, J Series
7 1016206-13 1 Cartridge, Pressure Reducing/Relieving, PO
8 1016206-12 1 Cartridge, Pressure Reducing/Relieving, DA
9 1016206-14 1 Cartridge, Solenoid, 3W/2P
10 984657-06 1 Coil, 12VDC Deutsch
11 1016206-08 1 Cartridge, Relief Valve, PO
12 1016206-20 2
Cartridge, Counterbalance Valve, 2.5:1
13 25496 1 Set Screw, 5/16-24 Thread
14 1016206-19 1 Cartridge, Flow Divider
15 988696-20 1 Cartridge, Direct Acting Relief
16 1016206-15 1 Cartridge, Solenoid, 3W/2P, Spool
17 986972-02 1 Coil, 12VDC Deutsch
18 1016206-11 5 Cartridge, PO Check Valve, 35 PSI
19 1016183-01 10 Cartridge, Check Valve, 5 PSI
Hydraulic - Manifold, Main Control - FA
NOTES:
1. Ensure the correct manifold manufacturer before ordering parts.
2. See Figure 6-37 for manifold schematic.
7
Illustrated Parts List (IPL)
Rosco CSV Variable Width Chip Spreader 7-31
