Item

No.

Part Number Qty. Description Remarks

1 1016183 1 Manifold, Auxiliary Function 1 Includes 2 - 15, See Notes

2 1016183-12 2 Cartridge, Proportional Flow Regulator, 15 GPM

3 1016183-10 4 Super Coil, 5/8 ID, 12VDC Deutsch

4 1016183-06 1 Cartridge, Proportional, NC, Compensated

5 1016183-05 1

Cartridge, Press. Reducing/Relieving Valve

6 1016183-02 1 Cartridge, Flow Regulator, Free Rev Flow Adj

7 988696-04 1 Cartridge, Solenoid, NC, Poppet

8 1016183-01 11 Cartridge, Check Valve, 5 PSI

9 1016183-07 2 Cartridge, Solenoid, 4W/3P, Float Center

10 986972-02 6 Super Coil, 5/8 ID, 12VDC Deutsch

11 1016183-09 1 Cartridge, Prop 4W/3P, Float Center, MO

12 1016183-04 4 Cartridge, PO Check Valve

13 1016183-03 3 Cartridge, Flow Regulator, Free Rev Flow Adj

14 1016183-09 2 Cartridge, Counterbalance Valve, 5:1

15 1016183-11 1 Cartridge, Check Valve

Hydraulic - Manifold, Work 1 - FA

NOTES:

1. Ensure the correct manifold manufacturer before ordering parts.

2. See Figure 6-38 for manifold schematic.

Illustrated Parts List (IPL)

Rosco CSV Variable Width Chip Spreader 7-33
