Item

No.

Part Number Qty. Description Remarks

1 1016205 1 Manifold, Auxiliary Function 2 Includes 2 - 12, See Notes

2 1016183-06 1 Cartridge, Proportional Poppet, NC, Compensated

3 1016183-10 1 Super Coil, 5/8 ID, 12VDC Deutsch

4 1016183-08 1 Cartridge, Prop 4W/3P, Float Center, MO

5 986972-02 3 Super Coil, 5/8 ID, 12VDC Deutsch

6 1016183-05 1 Cartridge, Pressure Reducing/Relieving Valve

7 1016183-09 2 Cartridge, Counterbalance Valve, 5:1

8 1016183-03 1 Cartridge, Flow Regulator, Free Rev Flow Adj

9 988696-04 1 Cartridge, Solenoid, NC Poppet

10 1016183-02 1 Cartridge, Flow Regulator, Free Rev Flow Adj

11 1016183-01 5 Cartridge, Check Calve, 5 PSI

12 1016183-11 1 Cartridge, Check Valve

Hydraulic - Manifold, Work 2 - FA

NOTES:

1. Ensure the correct manifold manufacturer before ordering parts.

2. See Figure 6-39 for manifold schematic.

Illustrated Parts List (IPL)

Rosco CSV Variable Width Chip Spreader 7-35
